Norbar 180246.B08.Ra Pts-80-2700 1" Sq. Dr. Right Angle

Norbar 180246.B08.Ra Pts-80-2700 1" Sq. Dr. Right Angle Contact Us for Pricing

The PTS is the result of an extensive design project to produce an efficient air motor, purpose built for this application in an accurate torque tool. The new air motor is then married to Norbar's respected gearbox range, sharing common torque reaction accessories with PTM and EvoTorque® tools.

The Right Angle Gearbox enables the benefits of Norbar's electronic torque tools to be brought to a host of applications from which they are currently excluded due to space restrictions.

Part number: 180246.B08.RA
EAN Bar Code: 5060207569569
NATO number: -
Accuracy: ±3%
Operates between: 540.00 - 2700.00 N·m
400.00 - 2000.00 lbf·ft

Square Size: 1"
Max Air Pressure: 6.5 bar
Tool Weight: 6.15 kg
Reaction Plate Weight: 1.4 kg
Free Speed: 7.3 rpm
