Norbar 18100.B06.Ra PTM-52 with Right Angle Gearbox, 500 N·m, Bi-Directional

Norbar 18100.B06.Ra Ptm-52 500 Bi Dir Stall Tool Right Angle G'Box Contact Us for Pricing

The PTM-52 is engineered to be one of the lightest and fastest tools of its type on the market. The exceptionally compact 52mm diameter gearbox means that the tool is well balanced, light weight and provides excellent access to bolts.

The Right Angle Gearbox enables the benefits of Norbar's electronic torque tools to be brought to a host of applications from which they are currently excluded due to space restrictions.

Part number: 18100.B06.RA
EAN Bar Code: 5060922230485
NATO number: -
Accuracy: ±5%
Operates between: 74.00 - 370.00 lbf·ft
100.00 - 500.00 N·m

Square Size: 3/4"
Max Air Pressure: 6.3 bar
Air Consumption: 19 litres/sec (40 CFM)
Free Speed: 224 rpm
Weight: 7.11kg
Height: 339mm
Length: 403mm
